ICON Stage 1 Shock System for 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 Toyota Land Cruiser 100 Series

Part: K53081

Overview:

The 1998 – 2007 Toyota Lancrusier 100 Series has a compact torsion bar IFS front suspension, and requires a lot of work to be done in a small space. When lift is added via torsion bar adjustment there is even more spring energy that must be absorbed to adequately control the vehicle. Understanding this, ICON engineers have developed a unique 2.5” diameter front shock that can handle these demands. With a lower spherical rod end bearing and heavy duty upper stem bushings, deflection is kept to a minimum for precise control of the suspension even under high loads. 2.0 Aluminum Series rear shocks are included in this stage to offer balanced damping front to rear.

Key Features:

• Vehicle specific tuned front and rear shocks for superior shock damping and control

• 6061 Aircraft grade aluminum CNC machined components• Corrosion resistant CAD plated front shock body with 7/8 shaft

• FK rod end bearings for extended longevity and minimal deflection

• 2.0 aluminum body rear IFP shock with 5/8″ shaft

• 100% Bolt-on – no drilling, cutting or welding necessary for install

• Made in the USA

Tech Info:

• Performance shock system for use with 0-2″ of lift. Additional components required to achieve desired lift height over stock

System Components:
57607    (QTY – 2)  – ICON V.S. 2.5 Series IFP 0-2″ Lift Front Shocks

56510    (QTY – 2)  – ICON 2.0 Aluminum Series Rear Shocks

Options:

57608     ICON V.S. 2.5 Series IFP 0-3″ Lift Front Shocks (upper control arm required)

57807     ICON V.S. 2.5 Series Remote Reservoir Front Shocks (upper control arm required)

57807C   ICON V.S. 2.5 Series Remote Reservoir Front Shocks w/ CDCV (upper control arm required)

57802     ICON V.S. 2.5 Series Remote Reservoir Rear Shocks

57802C   ICON V.S. 2.5 Series Remote Reservoir Rear Shocks w/ CDCV

No products were found matching your selection.

3747

on

ICON Stage 1 System 3″ Lift Kit for 1991, 1992, 1993, 1994, 1995, 1996, 1997 Toyota Land Cruiser 80 Series

Part: K53091

OVERVIEW:

After an in-depth R&D process, ICON engineers have developed a 3” suspension system for the 80 Series that is aimed to improve on-road handling characteristics while also maximizing the Land Cruiser’s off-road potential. This Stage 1 system includes ICON-designed dual rate coil springs, caster correction bushings, sway bar relocation components, all bracketry and hardware required for install, and ICON Vehicle Dynamics 2.0 Aluminum Series shocks that feature a vehicle specific valving for optimized ride quality and balanced damping front to rear. This ICON Stage 1 System is the perfect entry level suspension system for drivers seeking a quality on-road ride with exceptional off-road characteristics as well.


KEY FEATURES:
  • 3” lift height*
  • Approximately 40% increased front wheel travel over stock
  • Approximately 35% increased rear wheel travel over stock
  • ICON-engineered dual rate coil springs provide exceptional on-road ride quality and outstanding off-road performance
  • Vehicle specific tuned 2.0 Aluminum Series front and rear shocks offer superior shock damping and control
  • 2.0 aluminum body IFP shocks with 5/8″ shaft
  • Corrosion resistant anodized aluminum shock body
  • 6061 aircraft grade aluminum CNC machined components
  • 100% bolt-on design means no drilling, cutting or welding necessary for install
*Lift height measurement is based from a stock unloaded vehicle (with gas engine)

WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 4.625″ Backspace

Aftermarket Tires: 33 x 11.50

(Larger Tires May Fit but Fender Trimming and Modifications will be Required)




SYSTEM COMPONENTS:

53005 (QTY.1) | 91-97 LAND CRUISER 3″ FRONT DUAL RATE SPRING KIT

53006 (QTY.1) | 91-97 LAND CRUISER 3″ REAR DUAL RATE SPRING KIT

53007 (QTY.1) | 91-97 LAND CRUISER SWAY BAR RELOCATION KIT

53008 (QTY.1) | 91-97 LAND CRUISER CASTER CORRECTION KIT

53009 (QTY.1) | 91-97 LAND CRUISER BRAKE LINE KIT +3″

56509 (QTY.2) | 91-97 LAND CRUISER 80 0-3″ FRONT 2.0 VS IR

56510 (QTY.2) | 91-07 LAND CRUISER 80/100 0-3″ REAR 2.0 VS IR

6452

on

Fox 2.0 Rear Shocks for 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 Toyota Tundra

Part: 980-24-673

Priced per set of 2

The 2.0 Performance Series IFP smooth body shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable offroad handling in even the toughest conditions. The precision metal impact aluminum body increases cooling capacity and will never rust. Inside you will find our race-proven performance valving technology Our Internal Floating Piston (IFP) mono-tube design separates the shock oil from the high-pressure, nitrogen-charged gas chamber. The IFP eliminates oil aeration allowing maximum performance from the factory-tuned precision valving. The race developed high flow damping piston matched with application specific vavling provides the 2.0 Performance Series IFP shock a predicable ride quality capable of handling the roughest road conditions.

Specifications:

Body

  • 2.0″ Metal impacted 6061-T6 aluminum will resist rust over time

Body Plating

  • Clear-anodized for a durable finish

Internal Reservoir

  • Internal IFP mono-tube reservoir design separates shock oil from the high-pressure nitrogen

Components

  • Black-anodized, CNC-machined 6061-T6 billet aluminum

Shaft

  • 5/8″ hard chrome plated heat-treated alloy steel

Piston

  • Race-developed high-flow piston design

Valving

  • Application specific valving to maximize performance

Seals

  • Redundant sealing pack system main seal, wiper seal, scraper seal

Oil

  • JM92 Advanced Suspension Fluid for improved performance at variable temperatures

Bushings

  • Quiet nitrile rubber allows for increased suspension articulation

Mounting

  • Direct replacement for stock and aftermarket lifts kits
