Fox 2.0 Rear 0-1” Lift  Shocks for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma

Part: 980-24-670
Priced per set of 2

Extended Length (IN): 21.95 Inch
Compressed Length (IN): 13.85 Inch
Rod Diameter (IN): 5/8 Inch
Upper Mounting Style: Stem Mount-SM3
Lower Mounting Style: Eyelet Sleeve-ES5

The 2.0 Performance Series IFP smooth body shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable offroad handling in even the toughest conditions. The precision metal impact aluminum body increases cooling capacity and will never rust. Inside you will find our race-proven performance valving technology Our Internal Floating Piston (IFP) mono-tube design separates the shock oil from the high-pressure, nitrogen-charged gas chamber. The IFP eliminates oil aeration allowing maximum performance from the factory-tuned precision valving. The race developed high flow damping piston matched with application specific vavling provides the 2.0 Performance Series IFP shock a predicable ride quality capable of handling the roughest road conditions.

Specifications:

Body

  • 2.0″ Metal impacted 6061-T6 aluminum will resist rust over time

Body Plating

  • Clear-anodized for a durable finish

Internal Reservoir

  • Internal IFP mono-tube reservoir design separates shock oil from the high-pressure nitrogen

Components

  • Black-anodized, CNC-machined 6061-T6 billet aluminum

Shaft

  • 5/8″ hard chrome plated heat-treated alloy steel

Piston

  • Race-developed high-flow piston design

Valving

  • Application specific valving to maximize performance

Seals

  • Redundant sealing pack system main seal, wiper seal, scraper seal

Oil

  • JM92 Advanced Suspension Fluid for improved performance at variable temperatures

Bushings

  • Quiet nitrile rubber allows for increased suspension articulation

Mounting

  • Direct replacement for stock and aftermarket lifts kits
4447

on

ICON 0-1.5″ Lift Rear Shock 2.0 for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma 4WD

Part: 56503

Quantity: 2

OVERVIEW:

ICON Vehicle Specific (V.S.) 2.0 Aluminum Series shock absorbers are the ultimate in cost effective upgrades, specifically tailored by ICON engineers for your application. The V.S. 2.0 Aluminum Series shocks are a high quality upgrade for the everyday street driver and weekend warrior looking for improved on and off-road performance. Like all ICON shock absorbers, V.S. 2.0 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For those using their vehicle in extreme off road situations, consider the ICON V.S. 2.5 Series shock to handle extra abuse and punishment your suspension will need to endure.

KEY FEATURES:

  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with internal reservoir
  • One piece linear/digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 5/8” chrome plated hardened steel shaft resists corrosion and pits
  • 6061 aluminum rod end, top cap, and internals ensure strength and durability
  • Polyurethane bushings, zinc plated sleeves, and forged steel mounting stems for OE factory type fitment
  • 6063 anodized aluminum body and reservoir tubing for superb heat dissipation, excellent corrosion resistance, and high-tech appearance
  • Nitrile rubber top out bumper for noise free operation
  • 100% rebuildable
  • 100% revalveable

Shocks are in pairs.  Purchasing 1 set is enough for use on the rear of your Toyota Tacoma Truck.

2977

on

ICON Stage 2 0-2″ Lift Leveling System for 2011, 2012, 2013, 2014, 2015, 2016, 2017 Chevy & GMC 2500/3500 HD

Part: K78102

The 2011-2019 GM 2500HD/3500HD requires significant shock damping to comply with the massive spring rate of the factory torsion bar system. ICON Vehicle Dynamics has developed a range of suspension systems with optimized vehicle specific shock damping. These systems offer excellent on and off-road drivability. While driving the construction site or trails to your favorite dirt bike location, ICON wants you to get there in comfort just like your drive to work. ICON’s Stage 2 system is comprised of V.S. 2.5 Series piggyback front & rear shocks, and tubular Delta Joint upper control arms. The ICON vehicle specific tuned 2.5″ shocks are the key to attaining optimum ride quality and getting that desired comfort with the 3/4 & 1-ton working capability. Reservoir shocks ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. Additionally, ICON upper control arms add strength, durability, and when paired with extended travel shocks increases wheel travel 2″ over the OEM configuration.

This system features upper control arms with ICON’s patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

FEATURES & BENEFITS

  • Vehicle specific tuned 2.5″ front and rear shocks for superior shock damping and control
  • Improved ride quality over stock with no change in towing capacity
  • Wheel travel increase of 2″ over stock
  • 100% Bolt-on system – no drilling, cutting, or welding necessary for install
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant plated shock bodies

DOWNLOAD INSTALLATION GUIDE

TECH INFO:

  • OEM Wheels & Tires Fitment: Yes
  • Recommended Aftermarket Wheels: ICON Alloys | 18×9″ w/ 5.50″ Backspace / 12mm Offset
  • Recommended Aftermarket Wheels: ICON Alloys | 20×9″ w/ 5.50″ Backspace / 12mm Offset
  • Recommended Aftermarket Tires: 33″ x 11.50″ (Larger tires may fit but fender trimming and modifications will be required.)
  • APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
  • APPLICATION NOTE #65: NOT SOLD SEPARATELY, ONLY SOLD IN COMPLETE KIT FORM AS LISTED
  • APPLICATION NOTE #113: 26.13″ IS MAX MEASUREMENT FROM FENDER TO HUB, EXCEEDING THE MAXIMUM LIFT HEIGHT OF 26.13″ CAN LEAD TO COMPONENT FAILURE NOT COVERED BY ICON WARRANTY
  • Ships in multiple boxes

SYSTEM COMPONENTS:



  • 77701P (QTY: 1) | 01-UP GM HD 0-1″ REAR 2.5 VS PB / 07-UP GM 1500 4″ REAR 2.5 VS PB PAIR
  • 78724 (QTY: 1) | 11-19 GM HD 0-2″ 2.5 RR SHOCK SYSTEM W/ UCA

OPTIONS:

191011 | ICON tubular UCA uniball cover caps

1800

on

ICON 0-2″ Lift Stage 1 Suspension System for 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019 Chevy & GMC 2500/3500 HD

Part: K78101

OVERVIEW

The 2011-2019 GM 2500HD / 3500HD requires significant shock damping to comply with the massive spring rate of the factory torsion bar system. ICON Vehicle Dynamics has developed a range of suspension systems with optimized vehicle specific shock damping. These systems offer excellent on and off-road drivability. While driving the construction site or trails to your favorite dirt bike location, ICON wants you to get there in comfort just like your drive to work. ICON’s Stage 1 system is comprised of V.S. 2.5 Series IFP front shocks, 2.0 Aluminum Series IFP rear shocks, and tubular Delta Joint upper control arms. The ICON vehicle specific tuned 2.5″ shocks are the key to attaining optimum ride quality and getting that desired comfort with the 3/4 & 1-ton working capability. Additionally, ICON upper control arms add strength, durability, and when paired with extended travel shocks increases wheel travel 2″ over the OEM configuration.

This system features upper control arms with ICON’s patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

FEATURES & BENEFITS

  • Vehicle specific tuned 2.5″ front and rear shocks for superior shock damping and control
  • Improved ride quality over stock with no change in towing capacity
  • Wheel travel increase of 2″ over stock
  • 100% Bolt-on system – no drilling, cutting, or welding necessary for install
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant plated shock bodies

DOWNLOAD INSTALLATION GUIDE

TECH INFO:

  • OEM Wheels & Tires Fitment: Yes
  • Recommended Aftermarket Wheels: ICON Alloys | 18×9″ w/ 5.50″ Backspace / 12mm Offset
  • Recommended Aftermarket Wheels: ICON Alloys | 20×9″ w/ 5.50″ Backspace / 12mm Offset
  • Recommended Aftermarket Tires: 33″ x 11.50″ (Larger tires may fit but fender trimming and modifications will be required.)
  • APPLICATION NOTE #55: SHOCKS ARE FULLY SERVICEABLE. COILOVER HEIGHTS INDICATED ARE FOR A STOCK EQUIPPED VEHICLE
  • APPLICATION NOTE #65: NOT SOLD SEPARATELY, ONLY SOLD IN COMPLETE KIT FORM AS LISTED
  • APPLICATION NOTE #113: 26.13″ IS MAX MEASUREMENT FROM FENDER TO HUB, EXCEEDING THE MAXIMUM LIFT HEIGHT OF 26.13″ CAN LEAD TO COMPONENT FAILURE NOT COVERED BY ICON WARRANTY
  • Ships in multiple boxes

SYSTEM COMPONENTS:



  • 78722 (QTY: 1) | 11-19 GM HD 0-1″ 2.5 IR SHOCK SYSTEM W/ UCA
  • 76529 (QTY: 2) | 01-UP GM HD 0-1″ REAR 2.0 VS IR



OPTIONS:

77732P      2011-Up GM 2500HD / 3500 2wd & 4WD V.S. 2.5 Series piggyback reservoir front shocks for use with UCA (Pair)

77701P      2011-Up GM 2500HD / 3500 2wd & 4WD V.S. 2.5 Series piggyback reservoir rear shocks (Pair)

77701CP    2011-Up GM 2500HD / 3500 2wd & 4WD V.S. 2.5 Series piggyback reservoir w/ CDCV rear shocks (Pair)

191011      ICON tubular UCA dust cover caps
