Bilstein 5160 0-2″ Rear Shocks for 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 Toyota 4Runner Toyota FJ Cruiser

Part: 25-227611

Discontinued and replaced with:

Need both the front and the rear kit for 4Runner?

Need both the front and the rear kit for FJ Cruiser?

Rear Shocks (old part: 25-227611):

Series: 5160

Rear Right:

Collapsed Length (IN) 14.50
Extended Length (IN) 23.50

Part Number: 25-313130

Rear Left:

Collapsed Length (IN) 14.50
Extended Length (IN) 23.50

Part Number: 25-313154

Rear Shocks Fitment Notes: Without XREAS Suspension

Sold in sets of 2

5160 Series – Stock Mount Remote Reservoir

Get the benefits of a remote reservoir with Bilstein’s stock mount 5160 shocks.

The product benefits at a glance:

  • Bilstein’s industry leading monotube design
  • Unique digressive valving system instantly produces full damping capability
  • Remote reservoir dramatically increases shock oil capacity for even greater heat dissipation and damping sensitivity
  • Reservoir mounting configuration designed specifically for each vehicle application
  • Special swivel banjo fittings on the reservoir hose allow for 360 degrees of
    rotation
  • For increased wheel travel and more shaft movement, the floating/dividing piston is located in the reservoir
  • Bilstein’s exclusive Triple-C Technology® finish provides easy care and lasting great looks
  • Includes reservoir mounting kit and detailed instructions
  • Sold in sets of 2
  • Great for 0-2″ of rear lift!

Includes 2 Shocks

You can also purchase:

19723

on

Bilstein 5160 0-1.5″ Rear Lift 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma shocks

Part: 25-311259 (Old Part number: 25-242379)

Includes 2 Shocks

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

Collapsed Length (in) : 14.22

Extended Length (in) : 23.63

Collapsed Length (mm) : 361.1

Extended Length (mm) : 600.3

Finish : Zinc Plated

Reservoir : Yes

Body Design : Smooth Body (Non-Coilover)

Body Diameter (id) : 46mm

Replacement Mounting Kit : B4-KT1-Z008A00

Spring Seat Included : No

Billet Reservoir Clamp Included : Yes

Adjustable Damping : Non-Adjustable

California Proposition 65 : WARNING: Cancer & Reproductive Harm – www.P65Warnings.ca.gov

Old Part number: 25-242379

18353

on

TAC 2407

Firestone Ride-Rite Air bags.
Fits Toyota Tacoma 4×4 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019

Firestone Ride-Rite Air bags.
Fits ’05 and Up Tacoma 4×4, and 2WD PreRunner

  • System Type:Leaf Spring Mount
  • Load Capacity:4,800 lbs per pair
  • Bag/Spring Type:Double Convoluted
  • Installation Type:Bolt On, No Drilling Required
  • Inflation Method:Manual Inflation
  • Optional Compressor and Gauges sold separately
  • Height Sensor Optional or Included?:Optional
  • Lift kit compatible?:Yes, May Require Spacers

Keep The Vehicle Level,Level Off-Center Loads,Reduce Suspension Fatigue,Air Adjustments Improves The Ride,Reduce Bottoming Out,Increase Vehicle Stability.
RideRite heavy duty air helper spring kits provide up to 5000 lbs of leveling capacity while improving vehicle stability.

NOTE: Custom modifications to mounting brackets may be required for lifted applications to ensure air bags are properly supported.
