ICON Stage 1 0-3.5″ Lift Kit for 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2021, 2022, 2023, 2024 Toyota 4Runner, 2010, 2011, 2012, 2013, 2014 FJ Cruiser

Part: K53061

OVERVIEW:

This is our entry level suspension system for the 2010-UP Toyota 4Runner. The Stage 1 system works well in most on and off-road scenarios by significantly improving factory body roll and overall driving ability. ICON 2.5 Series front coilover shocks feature a vehicle-specific tune to give your Toyota 4Runner great ride quality on or off-road, and they are adjustable from 0 to 3.5″ of lift. Our rear 2.0 Aluminum Series shocks in this system are tuned to match the front 2.5 Series coilovers in every aspect, providing smooth and consistent damping performance front to rear. This system is finished off with a pair of 2″ lift rear coil springs that have been engineered to further improve ride quality and handling.

TECH INFO:

  • We recommend the use of our #56100 shock shin guards to reduce the chance of shock shaft damage. These shocks are located in a vulnerable position that allows debris to easily come in direct contact with the shock shaft.
  • KDSS Equipped vehicles require 54200 Rear Adjustable Track Bar
WHEEL & TIRE FITMENT INFO:

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 4.75″ Backspace

Aftermarket Tires: 33″ x 11.25

(Larger tires may fit but fender trimming and modifications will be required)

SYSTEM COMPONENTS:

58646 (QTY.1) | 10-UP 4RUNNER 2.5 SERIES IR COILOVER KIT

52700 (QTY.1) | 07-UP FJ/03-UP 4RUNNER REAR 2″ SPRING KIT

56505 (QTY.2) | 03-UP 4 RUNNER 1-3″ REAR 2.0 ALUMINUM SERIES IR SHOCK

OPTIONS:

58451DJ | Tubular Delta Joint upper control arms

58551DJ | Billet Delta Joint upper control arms

56100 | ICON Rear shock shin guards

54000 | Billet lower adjustable link arms

54100 | Billet upper adjustable link arms

54200 | Adjustable track bar

52800 | ICON Overland Series dual rate 3″ lift rear coil springs

56104 | Rear hydraulic bumpstop kit

191011 | ICON tubular upper control arm cover caps

198000 | ICON 2 pin spanner wrench

NOTE: Spanner wrench for adjustment is not included. Please purchase 198000 Spanner Wrench.
22242

on

Bilstein 5100 0-2.5″ Front and 0-2″ Rear shocks for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015 Toyota Tacoma 6 Lug

Part: 24-324359_24-186728

The Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are perfect for vehicles with front OE coilover style suspension. The 5100 shock absorbers feature multiple snap-ring grooves in the body for varying spring seat positions and provide 0-2.5 inches of front lift. The 46mm digressive piston and self-adjusting deflective disc valve setting improve handling and wheel travel. Leveling out your vehicle has never been easier with the Bilstein B8 5100 (Ride Height Adjustable) shock absorber.

Fitment Notes: Please note, these shock absorbers will not work on the 5-Lug Tacoma. Ride heights are an approximation and can vary based on your vehicle’s factory suspension, condition, optional equipment and accessories, and other modifications like replacement coil springs, wheel and tire combinations, etc.

FRONT:

2 x 24-324359 (old part: 24-239370)

  • Extended Length (IN): 22.56 Inch
  • Compressed Length (IN): 17.03 Inch
  • Rod Diameter (IN): 1.81 Inch
  • Upper Mounting Style: Stem
  • Lower Mounting Style: Eyelet

Installation instructions for 24-186728 are included.

REAR:

2 x 24-186728

  • Extended Length (IN): 22.94 Inch
  • Compressed Length (IN): 14.02 Inch
  • Rod Diameter (IN): 1.81 Inch
  • Upper Mounting Style: Stem
  • Lower Mounting Style: Eyelet

Please note, the rear 5100 shocks are not adjustable. The kit includes 4 shocks.
