FOX Factory Race Series 2.5 Internal Bypass 0-1.5″ Rear Lift Shocks for 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 Toyota Tacoma 4WD

Part: 883-26-123

FOX Factory Race Series 2.5 Internal Bypass shocks for the Toyota Tacoma deliver velocity and position-sensitive damping technology, Dual Speed Compression (DSC) adjustment, and high-speed ready performance in a bolt-on kit.

Patented Internal Bypass technology allows for multiple zones of damping control. The result is a comfortable, confident ride with increased damping capacity through rough terrain. Internal bypass shocks produce more force progressively to control hard bottom-outs, prevent harsh top-outs, and provide an initial catch for landing. Shock fluid bypasses the main piston through a series of bleed holes in the ride zone. As the shock extends past the ride zone in rebound or compression, the bleed holes terminate, forcing fluid through the main piston.

Type III anodization prevents corrosion and wear of the 2.5-inch diameter aluminum bodies. Dial in your Tacoma for load, environment, and driving style with the DSC adjuster. External reservoirs increase oil capacity and house an internal floating piston (IFP) to separate the shock oil and nitrogen charge, maintaining consistent damping and keeping shock temperatures cool.

Experience the support and confidence of FOX Internal Bypass shocks you need while driving high-speed through rugged terrain.

PART NUMBER 883-26-123
SERIES Factory
TRAVEL 8.55
BODY 2.5″ impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
BODY PLATING Hard-anodized for a durable finish
SHAFT 7/8″ hard chrome plated heat-treated alloy steel
PISTON Race-developed high-flow piston design
VALVING Application specific valving to maximize performance
SEALS Redundant sealing pack system main seal, wiper seal, scraper seal
BEARINGS PTFE-lined, heat-treated, alloy steel spherical
EXTENDED LENGTH 22.9
COMPRESSED LENGTH 14.35
TOP MOUNT Stem Top
BOTTOM MOUNT Eyelet
FITMENT NOTES
8

on

Bilstein 4600 Assembled Front Coilovers and Rear Shocks for 2017, 2018, 2019, 2020, 2021, 2022, 2023 Nissan Titan

Part: 4600BILNTNX07

Bilstein B6 4600 shock absorbers are designed as a direct fit upgrade to OE shock absorbers on stock height light trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B6 4600 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B6 4600 shock absorbers are tuned for each specific application to ensure optimal performance is achieved. B6 4600 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Finish: Yellow Paint
Reservoir: No
Body Design: Snap Ring Grooved Body (Coilover)
Body Diameter: 46mm
Assembled with OE Replacement coils

Includes Coilovers exactly as pictured

Assembly may take 2-7 days

2036

on

Bilstein B8 5160 Rear 5″ Rear Lift Shocks for 2011, 2012, 2013 Ram 2500

Part: 25-311761

Notes:

  • Fits Vehicles With 5″ Rear Lift
  • Without Z55 Autoride Suspension Package
  • Without ZW7 Premium Smooth Ride Nivomat Suspension

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

Collapsed Length (in) :16.56

Extended Length (in) :28.13

Collapsed Length (mm) :420.5

Extended Length (mm) :714.7

Finish :Zinc Plated

Reservoir :Yes

Body Design :Smooth Body (Non-Coilover)

Body Diameter (id) :46mm

Spring Seat Included :No

Billet Reservoir Clamp Included :Yes

Adjustable Damping :Non-Adjustable

8

on

Bilstein B8 5160 Rear 5″ Rear Lift Shocks for 2011, 2012 Ram 3500

Part: 25-311761

Notes:

  • Fits Vehicles With 5″ Rear Lift
  • Without Z55 Autoride Suspension Package
  • Without ZW7 Premium Smooth Ride Nivomat Suspension

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

Collapsed Length (in) :16.56

Extended Length (in) :28.13

Collapsed Length (mm) :420.5

Extended Length (mm) :714.7

Finish :Zinc Plated

Reservoir :Yes

Body Design :Smooth Body (Non-Coilover)

Body Diameter (id) :46mm

Spring Seat Included :No

Billet Reservoir Clamp Included :Yes

Adjustable Damping :Non-Adjustable
