Fabtech 3.5″ Ball Joint UCA Lift Kit for 2011-2019 Chevrolet Silverado 3500 2WD/4WD with Stealth Shocks

Name: Fabtech 3.5" Ball Joint UCA Lift Kit for 2011-2019 Chevrolet Silverado 3500 2WD/4WD with Stealth Shocks
Brand: Fabtech
SKU: K1055M_n1
Availability: InStock

SKU: K1055M_n1

Fabtech 3.5 Ball Joint UCA Lift Kit for 2011-2019 Chevrolet Silverado 2500 2WD-4WD with Stealth Shocks

Description
Fabtech 3.5″ Ball Joint UCA Lift Kit for 2011-2019 Chevrolet Silverado 3500 2WD/4WD with Stealth Shocks

Fabtech 3.5″ Ball Joint UCA Lift Kit for 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019 Chevrolet Silverado 3500 2WD/4WD with Stealth Shocks

Part: K1055M_n1

Our 3.5” System provides less lift than our 6” RTS™ system but still allows use of 33” or 35” tall tires with cutting for street and offroad use. We have developed this system utilizing replacement upper control arms constructed of 1.50” OD .120” thick wall DOM tubing that attaches to heavy duty Fabtech ductile iron steering knuckles. The factory torsion bars remain in the stock position and use new forged adjusting keys to provide the proper amount of lift.

This system will level the stance of the vehicle compared to the factory nose down rake with no change to the rear suspension. For those customers that require a factory nose down appearance an optional 1″ rear block kit is available (2500HD Part # FTS21110) or (3500HD Part # FTS21111).

FEATURES

Upper Control Arms Built With Same Materials Found On Trophy Trucks
.120″ Wall 4130 Chromoly Tubing. 1.50″ OD
.250″ wall DOM Bushing Barrels
Extended Range Ball Joints
Ductile Iron Steering Knuckles
Forged Torsion Bar Keys

PART NUMBERS

QTY	PART #	DESCRIPTION
1	FTS21184	COMPONENT BOX W/STEALTH SHOCKS

TIRES & WHEELS

Tire Size – 33/12.50R18 Wheel Size – 18×9 w/ 5 3/4in BS w/minor trimming
Tire Size – 33/12.50R20 Wheel Size – 20×9 w/ 5 3/4in BS w/minor trimming
Tire Size – 35/13.50R18 Wheel Size – 18×9 w/ 5 3/4in BS w/fenderwell cutting
Tire Size – 35/13.50R20 Wheel Size – 20×9 w/ 5 3/4in BS w/fenderwell cutting

INCLUDED SHOCKS:

STEALTH MONOTUBE SHOCK

Stealth is the first all black monotube shock absorber, with an identifiable raised metal nameplate, that represents the signature of quality you can rely on for a superior ride at an affordable price.

Stealth monotube shocks are built with a 46mm diameter high flow piston and vehicle specific valving, for a great ride with oversized tires.

All Stealth shock absorbers feature Nitrocarburized piston rods that are superior to chromed rods in durability and corrosion resistance. These Nitrocarb piston rods are finished in matte black for a complete black out shock package.
