Zone Offroad 6″ Lift Kit 2000-2006 Chevy/GMC Suburban & SUV 1500 4WD

Description
Zone Offroad 6″ Lift Kit 2000-2006 Chevy/GMC Suburban & SUV 1500 4WD

Zone Offroad 6″ Lift Kit 2000, 2001, 2002, 2003, 2004, 2005, 2006 Chevy/GMC Suburban & SUV 1500 4WD

Part: C7

The Zone Offroad suspension system for the Chevy and GM SUV’s is designed for an everyday driver, but built to handle offroad abuse. The lower control arm crossmembers match the factory geometry and appearance. Combined with the CNC machined steering knuckles, the critical components are relocated to factory specs creating a true factory quality driving experience. The differential skid plate combined with the compression struts for added frame support creates an extremely solid system. The rear is lifted with new coil springs, with a track bar bracket and sway bar links included. If you’ve been shopping for the best deal on a lift, look no further.

Featured Technology & Benefits

• Ductile Iron, CNC machined steering knuckles maintain OE steering geometry.
• Heavy duty boxed one piece crossmembers.
• Differential skid plate and compression struts are included for off-road protection.
• Multi-point differential mounting system corrects drive line angles.

Important Notes!

• Will not fit vehicles equipped with Auto-Ride
• Not recommended for all wheel drive (AWD) models
• Torsion bar tool required for installation.
• Frame bracket modification and minor welding required.
• If equipped with factory 17″ wheels, then they must be replaced with 17″ or larger aftermarket wheels.
• Stock tires & wheels can be installed back on the vehicle, but larger tires cannot be installed on factory wheels.

This product fits the following applications:

• 2002 Chevy Avalanche 1500 4WD Gas
• 2003 Chevy Avalanche 1500 4WD Gas
• 2004 Chevy Avalanche 1500 4WD Gas
• 2005 Chevy Avalanche 1500 4WD Gas
• 2006 Chevy Avalanche 1500 4WD Gas
• 2000 Chevy Suburban 1500 4WD Gas
• 2001 Chevy Suburban 1500 4WD Gas
• 2002 Chevy Suburban 1500 4WD Gas
• 2003 Chevy Suburban 1500 4WD Gas
• 2004 Chevy Suburban 1500 4WD Gas
• 2005 Chevy Suburban 1500 4WD Gas
• 2006 Chevy Suburban 1500 4WD Gas
• 2000 Chevy Tahoe 4WD Gas
• 2001 Chevy Tahoe 4WD Gas
• 2002 Chevy Tahoe 4WD Gas
• 2003 Chevy Tahoe 4WD Gas
• 2004 Chevy Tahoe 4WD Gas
• 2005 Chevy Tahoe 4WD Gas
• 2006 Chevy Tahoe 4WD Gas
• 2000 GMC Yukon 4WD Gas
• 2001 GMC Yukon 4WD Gas
• 2002 GMC Yukon 4WD Gas
• 2003 GMC Yukon 4WD Gas
• 2004 GMC Yukon 4WD Gas
• 2005 GMC Yukon 4WD Gas
• 2006 GMC Yukon 4WD Gas
• 2000 GMC Yukon XL 1500 4WD Gas
• 2001 GMC Yukon XL 1500 4WD Gas
• 2002 GMC Yukon XL 1500 4WD Gas
• 2003 GMC Yukon XL 1500 4WD Gas
• 2004 GMC Yukon XL 1500 4WD Gas
• 2005 GMC Yukon XL 1500 4WD Gas
• 2006 GMC Yukon XL 1500 4WD Gas

Quick Specs

• Front Lift Height: 6″
• Front Lift Method: IFS System w/Knuckle
• Rear Lift Height: 5 1/2″
• Rear Lift Method: Coil Springs
• Install Time Hrs: 8
• Difficulty Level 1-5: 3
• Wheel Size: 16 or 17 x 8
• Back Spacing: 4.5
• Max Tire Size: 33 x 12.50
• Wheel Size: 18×9
• Back Spacing: 5
• Max Tire Size: 34×12.50
• Wheel Size: 20×9
• Back Spacing: 5.75
• Max Tire Size: 35×12.50
