Falcon 2.25″ Lift Sport Tow/Haul Shock Leveling System for 2015-2023 Ford F-150.

Description
Falcon 2.25″ Lift Sport Tow/Haul Shock Leveling System for 2015-2023 Ford F-150.

Falcon 2.25″ Lift Sport Tow/Haul Shock Leveling System for 2015-2023 Ford F-150.

05-04-32-400-002

Introducing the Falcon Lift 2.25″ Sport Tow/Haul Shock Leveling System for 2015-2023 Ford F-150. Easily adjust your suspension tuning for sport or work duties with three simple and distinct settings. The rear piggyback shocks with easy-to-use 3-position Fast Adjust Knob’s setting range from Sport, Moderate Tow/Haul, and Heavy Tow/Haul.

This shock system provides professional-grade adjustable shocks, the perfect solution for your truck’s performance. The shocks use progressive valving technology to provide fast rebound and consistent damping control, allowing for improved stability and increased ride comfort.

These shocks are designed to last even with years of heavy-duty use. The shocks have an extended wind span and features nitrogen-filled, monotube technology along with an improved, 10-stage velocity sensitive valving system. Plus, for maximum resistance to corrosion, the shocks are zinc-plated for ultimate protection.

Towing and Hauling? You’re covered. Falcon’s Tow/Haul setting captures the benefit of their latest valving technology to enhance towing and hauling performance. On the inside, you’ll find a mechanical fast adjust knob that can quickly and easily be adjusted to any of the three settings.

The polished black frame and heavy-duty EPDM rubber bushings also provide superior strength and stability, delivering outstanding performance on the road. So upgrade your Ford F-

Truck/SUV Performance Shocks:
• Vehicle-specific shock absorbers
• Race-inspired performance for increased vehicle stability
• Improved dynamic roll control and low-speed damping
• Dramatic improvement in on-road comfort and off-road performance
• Optimized fitment for unobstructed suspension travel and articulation
• 2.3” shock body provides optimal performance
• 6061-T6 aluminum alloy shock body resists Impact to protect internal components
• Smooth honed internal shock body surface for long-term performance
• 3/4” induction hardened chrome plated shaft resists rock damage, corrosion, and shaft buckling
• Large shaft diameter provides wide range of adjustment on adjustable shocks
• Hard anodized 6061-T6 aluminum alloy billet piston
• 1-piece Teflon bronze piston wear band w/ O-ring
• VOD (Volume Optimized Damping) features a digressive linear piston
• VOD reduces shock bottoming at full compression or over uneven terrain
• OGS (Oil/Gas Separator) prevents cavitation
• ZRT (Zone Rate Tuning) assists factory spring in the Extension Zone and Compression Zone during aggressive driving — does NOT affect Drive Zone
• Internal Negative-Rate Coil Spring eliminates top out clunk and shock stress during Extension Zone; softens tire landing on impact
• Vehicle tuned microcellular Progressive Bump Stops reduce harsh bottom outs (when applicable)
• High-quality spherical bushings (when applicable)
• Zerk fittings to lube bushing (when applicable)
• Red Line synthetic oil w/ a high Viscosity Index for consistent performance across all temperatures
• Synthetic formula also contains special anti-wear and lubricity agents
• 1,000-hour salt spray corrosion resistance test on all hardware
• Serviceable and rebuildable (factory serviced)
• Designed, engineered, and assembled in-house from domestic and globally sourced components
• Patented design
• 3-year warranty

Vehicle(s):
• 2021+-2020 Ford F-150 (14th-gen) – does NOT fit Raptor or Lightning
• 2015-2020 Ford F-150 (13th-gen) – does NOT fit Raptor Specs:
• Front Level Height: 0–2.25”
• Max Tire Size: 285/70R17

Falcon Performance Shocks improve performance and comfort regardless of the terrain. Adjust your suspension tuning for sport or work duties with Falcon Sport Tow/Haul Shocks. These systems pair front monotube shocks with rear adjustable piggyback shocks. The easy-to-use 3-position Fast Adjust Knob’s settings include Sport, Moderate Tow/Haul, and Heavy Tow/Haul. The versatility of these systems makes them ideal for daily driving, off-road excursions, and tow/haul duties. Falcon Shock Leveling Systems provide multiple ride heights to level the front end and/or compensate for the additional weight of a winch or other accessories. “High-Value Performance” is the driving force behind our vehicle-specific dampers for Jeeps, trucks, and SUVs. We don’t re-valve existing shocks (like other companies); we engineer complete shock absorber systems that improve the overall performance of your truck or SUV both on and off road and while towing. Falcon Performance Shocks by TeraFlex. Sport Tow/Haul Shocks:
• Sport Tow/Haul Shocks increase stability and control as well as improve ride quality and comfort both on and off-road in a compact and affordable package
• Front monotube shocks w/ optimized tuning for on- and off-road driving
• Rear adjustable piggyback shocks w/ 3-position Fast Adjust Knob for large damping adjustments
• Rear settings include: Sport, Moderate Tow/Haul, Heavy Tow/Haul
• ideal for daily driving, off-road excursions, and tow/haul duties as well as the serious enthusiast wanting a consistent, controlled feel through all driving conditions Front Leveling Shocks:
• Front leveling shocks w/ multiple snap ring grooves provide a range of height adjustment Rear Piggyback Shocks:
• Piggyback design increases oil and gas capacity for reduced heat
• Flows 6x more oil than restrictive reservoir hose designs
• Eliminates common leakage issues found in banjo and swivel fittings

Fits these vehicle years: 2015|2016|2017|2018|2019|2020|2021|2022|2023
