Bilstein 5125 8″ Front, Rear Shocks For 2000-2004 Ford F-350 Super Duty 4WD Diesel

SKU: 84056_n1
5 out of 5 based on 1 customer rating
(1 customer review)
Sale!
Bilstein 5100 8" Front, Rear Shocks For 2000-2004 Ford F-350 Super Duty 4WD Diesel
Bilstein 5100 8" Front, Rear Shocks For 2000-2004 Ford F-350 Super Duty 4WD Diesel

Description
Bilstein 5125 8″ Front, Rear Shocks For 2000-2004 Ford F-350 Super Duty 4WD Diesel

Bilstein 5125 8″ Front, Rear Shocks For 2000, 2001, 2002, 2003, 2004 Ford F-350 Super Duty 4WD Diesel

Part: 84056

Front Shock Specifications:

Collapsed Length (IN)17.91
Extended Length (IN)29.70
Collapsed Length (MM)455.0
Extended Length (MM)754.5
Compression @0.52m/s700
Rebound @0.52m/s2550
Finish Zinc Plated
Reservoir No
Body Design Smooth Body (Non-Coilover)
Body Diameter 46mm
Spring Seat Included No
Adjustable Damping Non-Adjustable
Replacement Mounting KitB4-KT1-Z236A00

made by Bilstein USA for SuperLift lift kits

  • Bilstein 5125 Series Shock Pack
  • 46mm monotube design ensures consistent, fade-free performance in all conditions
Include:
  • Front and Rear Shock Pack
  • Detailed instruction manual walking you step-by-step through the lift kit installation procedures suitable for do-it-yourselfers (DIY) or professional installation

BILSTEIN 5125, FOR THE ROCKY ROAD AHEAD.

The BILSTEIN 5125 series is perfect for lifted trucks and SUVs.

Due to their larger tires and heightened stance, lifted vehicles place extra demands on a shock absorber‘s damping ability. The 5125‘s monotube design and patented digressive valving is uniquely suited to confront these demands. On or off-road, loaded or unloaded, the BILSTEIN 5125 shock absorber instantly reacts to changing road inputs to maintain a stable, controlled, and comfortable ride.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Patented digressive valving instantly reacts to changing surface conditions
  • OEM certified mounting hardware allows for easy installation
  • Zinc plated for resistance against harsh elements
  • Durable vulcanized neoprene rubber bushings
  • Made in the USA or Germany

Rear Shock Specifications:

Collapsed Length (IN)20.77
Extended Length (IN)34.92
Collapsed Length (MM)527.5
Extended Length (MM)887.0
Compression @0.52m/s700
Rebound @0.52m/s2550
FinishZinc Plated
ReservoirNo
Body DesignSmooth Body (Non-Coilover)
Body Diameter46mm
Spring Seat IncludedNo
Adjustable DampingNon-Adjustable
Replacement Mounting KitB4-KT1-Z236A00

INSTALLATION:

  • Installation time: 1-3 hours
  • Difficulty level: 2 of 5

Customer reviews

Rated 5 out of 5 stars
1 review
5 stars 1 100 %
4 stars 0 0 %
3 stars 0 0 %
2 stars 0 0 %
1 star 0 0 %

1 review for Bilstein 5125 8″ Front, Rear Shocks For 2000-2004 Ford F-350 Super Duty 4WD Diesel

    Add a review

    Use one of the allowed file type: jpg,png,jpeg.

      Questions and answers of the customers

        Is there a different part number for his same setup but for 6.2L gas trucks? Having trouble finding one that will fit with my lift that doesn’t specify diesel. Figured there would be a difference due to the lighter weight of the gas engine but wasn’t sure. Thanks.
      1. 0 votes
        QIs there a different part number for his same setup but for 6.2L gas trucks? Having trouble findi...... Read more answer now
        A All we can offer https://www.suspensionlifts.com/product-category/ford/f350/1999-2004-f350/?swoof=1&pa_product-type=shocks&pa_4wd2wd=4wd&really_curr_tax=897-product_cat&perpage=90 But pay attention to the type of suspension you have Front:Leaf Rear:Leaf or Front:Coil Rear:Leaf
        2. Will these fit 2008 F-350? Have been looking for Bilstein 5100 front and rear shocks for 8inch lift for this year make and model for days with no luck.
      2. 0 votes
        QWill these fit 2008 F-350? Have been looking for Bilstein 5100 front and rear shocks for 8inch li...... Read more answer now
        A  can offer for 2008 4wd https://www.suspensionlifts.com/shop/ford/f350/2005-2016-f350/05-16-ford-f350-super-duty-4wd-8-5-front-8-5-rear-lift-skyjacker-mono-shocks/https://www.suspensionlifts.com/?swoof=1&pa_vehicle-year=2008&pa_make=ford&pa_model=f-350&pa_lift=7,7-5,8,8-5,9
