Bilstein B8 5160 Front 6″ and 4″ Rear Lift Reservoir Shocks for 2014-2024 Ram 2500 4WD

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting, providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

FRONT SHOCKS SPECIFICATIONS:

Collapsed Length (IN) 17.08
Extended Length (IN) 26.75
Collapsed Length (MM) 433.8
Extended Length (MM) 679.5
Finish Zinc Plated
Reservoir Yes
Body Design Smooth Body (Non-Coilover)
Body Diameter 46mm
Replacement Mounting Kit B4-KT1-Z270A01

REAR SHOCKS SPECIFICATIONS:

Collapsed Length (IN): 18.66
Extended Length (IN): 28.23
Collapsed Length (MM): 474.0
Extended Length (MM): 717.0
Finish: Zinc Plated
Reservoir: Yes
Body Design: Smooth Body (Non-Coilover)
Body Diameter: 46mm
Optional Reservoir Clamp: N/A
Replacement Mounting Kit: B4-KT1-Z223A01

Notes:

• For Rear Lifted Height: 4″
• Without Air Leveling Suspension
