Fox 2.0 Perf Series 6″ Front Lift Reservoir and 6″ Rear Lift Perf Shocks for 2014-2024 Ram 2500 4WD

SKU: 885-24-234_2x985-24-201
Sale!

Description
Fox 2.0 Perf Series 6″ Front Lift Reservoir and 6″ Rear Lift Perf Shocks for 2014-2024 Ram 2500 4WD

Fox 2.0 Perf Series 6″ Front Lift Reservoir and 6″ Rear Lift Perf Shocks for 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 Ram 2500 4wd

Part: 885-24-234_2x985-24-201

Includes 2 Shocks

The aluminum bodied Performance Series 2.0 Reservoir smooth body shock delivers FOX’s industry leading and race dominating performance in an affordable, hassle-free bolt on package. Its heat reducing design includes a metal impacted clear anodized aluminum shock body that dissipates heat faster than a conventional steel body shock.

Its external reservoir allows for increase oil and nitrogen capacity while delivering a striking race look. The included black anodized reservoir mounting clamp and other components are CNC machined from 6061-T6 aluminum. The race developed high flow damping piston matched with application specific valving provides the Performance Series 2.0 Reservoir shock a predicable ride quality capable of handling the roughest road conditions.

Features and Specifications:


Body2.0″ Impact extruded 6061-T6 aluminum will resist rust over time
Body PlatingClear-anodized for a durable finish
Reservoir2.0″ Smooth bore 6061-T6 Aluminum is hard anodized
ComponentsBlack-anodized, CNC-machined 6061-T6 billet aluminum
Shaft5/8″ hard chrome plated heat-treated alloy steel
PistonRace-developed high-flow piston design
ValvingApplication specific valving to maximize performance
SealsRedundant sealing pack system main seal, wiper seal, scraper seal
BushingsQuiet nitrile rubber allows for increased suspension articulation
Extended26.370
Compressed16.750
Travel9.620
Top MountStem Top
Bottom MountEyelet

REAR SHOCK SPECIFICATION:

The Performance Series 2.0 IFP smooth body shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions.

The precision metal impact aluminum body increases cooling capacity and will never rust. Inside you will find our race-proven performance valving technology. Our Internal Floating Piston (IFP) mono-tube design separates the shock oil from the high-pressure, nitrogen-charged gas chamber. The IFP eliminates oil aeration allowing maximum performance from the factory-tuned precision valving. The race developed high flow damping piston matched with application specific valving provides the Performance Series 2.0 IFP shock a predicable ride quality capable of handling the roughest road conditions.


Body2.0” Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time
Body PlatingClear-anodized for a durable finish
ReservoirInternal IFP mono-tube reservoir design
ComponentsBlack-anodized, CNC-machined 6061-T6 billet aluminum
Shaft5/8″ hard chrome plated heat-treated alloy steel
PistonRace-developed high-flow piston design
ValvingApplication specific valving to maximize performance
SealsRedundant sealing pack system main seal, wiper seal, scraper seal
BushingsQuiet nitrile rubber allows for increased suspension articulation
Extended28.640
Compressed17.650
Travel10.990
Top MountStem Top
Bottom MountEyelet

Customer reviews

Reviews

There are no reviews yet.

Be the first to review “Fox 2.0 Perf Series 6″ Front Lift Reservoir and 6″ Rear Lift Perf Shocks for 2014-2024 Ram 2500 4WD”

Use one of the allowed file type: jpg,png,jpeg.

    Questions and answers of the customers

      Do these shocks include reservoir mount brackets for the front shocks? Thanks
    1. 0 votes
      QDo these shocks include reservoir mount brackets for the front shocks? Thanksanswer now
      A yes, comes with reservoir mountings hardware
