ICON 0-3.5″ Lift Kit Stage 2 with Tubular UCAs for 2003-2009 Toyota 4Runner, 2007-2009 FJ Cruiser

This ICON Stage 2 suspension system for the 2003-2009 Toyota 4Runner uses the same components as the Stage 1 system with a few simple changes and additions. The 2.5 Series coilover shocks used in this system are the Extended Travel version, offering increased wheel travel that will enhance your on and off-road performance even more so than the standard travel units. Since these shocks do provide more suspension travel, they require the use of an ICON upper control arm.

This system features upper control arms with ICON’s patent pending Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

TECH INFO:

• We recommend the use of our #56100 shock shin guards to reduce the chance of shock shaft damage. These shocks are located in a vulnerable position that allows debris to easily come in direct contact with the shock shaft.

OEM Wheels & Tires: Yes

Aftermarket Wheels: 8-8.5″ Wide, 4.75″ Backspace

Aftermarket Tires: 33″ x 11.25

(Larger tires may fit but fender trimming and modifications will be required)

SYSTEM COMPONENTS:

58645 (QTY.1) | 03-09 4RUNNER EXT TRAVEL 2.5 SERIES IR COILOVER KIT

58451DJ (QTY.1) | 03-UP 4RUNNER TUBULAR DELTA JOINT UCA KIT

52700 (QTY.1) | 07-UP FJ/03-UP 4RUNNER REAR 2″ SPRING KIT

56505 (QTY.2) | 03-UP 4 RUNNER 1-3″ REAR 2.0 ALUMINUM SERIES IR SHOCK

OPTIONS:

56100 | ICON Rear shock shin guards

54000 | Billet lower adjustable link arms

54100 | Billet upper adjustable link arms

54200 | Adjustable track bar

52800 | ICON Overland Series dual rate 3″ lift rear coil springs

56104 | Rear hydraulic bumpstop kit

191011 | ICON tubular upper control arm cover caps

198000 | ICON 2 pin spanner wrench
